Cover M4A4 Sherman Workshop Manual
Enlarged view
Workshop Manual · English

M4A4 Sherman Workshop Manual

US Army Technical Manual TM 9-754 · Medium Tank M4A4 · Re-typeset English Edition

Choose edition
German English

Restore the legendary Medium Tank M4A4 with this restored original English workshop manual. Includes operating, maintenance, and lubrication data.

492 pages · SKU OD-TM9754-EN

⚡ PDF: instant download 🇩🇪 Book printed in Germany 🔒 Secure payment 📐 Layout true to the original

Independent edition of a public-domain document. Brand names are used solely to describe the product.

Description

Discover the newly typeset and restored edition of the original historical workshop manual for the Medium Tank M4A4. Written in authentic English, this essential technical publication provides deep mechanical insights for historians, collectors, and vehicle restorers. Explore foundational chapters detailing operating instructions, organization instructions, and vehicle characteristics, including specific data on power units, cooling systems, fuel and oil, armament, ammunition carried, communication, and armor thickness. Master daily operations through structured sections covering operation and controls, prestarting preventive maintenance, starting the power unit, gear shifting, brakes, and stopping procedures. Ensure optimal vehicle performance with comprehensive guidance on preventive maintenance routines spanning prestarting, during operation, halts, and milestone checks after 50 or 100 hours of use. Additional specialized chapters cover detailed lubrication instructions for the medium tank and the combination gun mount M34, care and preservation protocols, cleaning records, plus an exhaustive breakdown of onboard tools, equipment, gun tools, spare parts, and accessories for the 75-mm gun and the overall vehicle.

From the contents

  • Medium Tank M4A4
  • Operating Instructions
  • Organization Instructions
  • Introduction and Vehicle Characteristics
  • Operation and Controls
  • Preventive Maintenance
  • Armament and Ammunition Stowage
  • Lubrication Instructions for Medium Tank M4A4
  • Lubrication Instructions for Combination Gun Mount M34
  • Care and Preservation
  • Tools and Equipment on the Vehicle
  • Spare Parts and Accessories for Vehicle

For restoration and workshop

When restoring a Sherman M4A4, the original documentation decides: torque values, lubricant specifications, adjustment dimensions and test procedures come straight from the original issued by the US Army, not second-hand. The layout-true reconstruction keeps every technical drawing and table in its original position, so page references from forums and literature still hold.

Matching 3D-printed spare parts for your classic are in our catalogue, or ask for a part that is no longer available.
